Description
A failed drive replaced at night starts with factory settings. This workbook keeps every VFD's settings and fault history in one place, so a technician can restore a drive in minutes and spot drives that keep tripping.
What’s included
- Drive register with make, rating, motor data and age flag (10+ years highlighted)
- Parameter record for up to 10 drives – motor data, control, protection, I/O, comms, PID
- Fault log with automatic repeat-fault detection and downtime totals
- Trip guide for 9 fault families: overcurrent, overvoltage, earth fault, overtemperature and more
- Safety notes on DC bus discharge and testing
Who it is for
HVAC and plant maintenance engineers, drive service technicians and facility managers.
Format
Excel workbook (Excel and Google Sheets). Sample data is filled in so you can see how it works before entering your own.
Frequently asked questions
Does it work in Google Sheets?
Yes. Excel files open in Microsoft Excel, Google Sheets and LibreOffice. Word files open in Word and Google Docs.
How do I get the files?
The download link appears right after payment and is emailed to you. You can download again from My Account for 365 days.
Can my team use it?
Yes, anyone in your own organisation may use it. Please do not resell or publish the files.
