Description
Most HVAC start-up problems come from something missed before the first start – a wrong overload setting, an untested fire interlock, a cable never insulation-tested. This checklist makes sure every electrical check is done and signed off before AHUs, chillers, pumps and fans are energised.
What’s included
- 44 checks in 8 sections: documents, panel, cables, motor, protection, interlocks, first run and handover
- Excel version with OK / Not OK / NA / Pending drop-downs and automatic completion %
- ‘Ready for commissioning’ indicator that only turns on when every item is closed
- Test-readings sheet: IR, winding resistance, voltage and current unbalance with PASS / CHECK
- Sign-off block for electrical contractor, HVAC contractor, consultant and client
- Printable PDF version for site use
Who it is for
HVAC and electrical contractors, MEP consultants, project engineers and facility teams taking over new plant.
Format
Excel workbook + printable PDF. Sample data is filled in so you can see how it works before entering your own.
Frequently asked questions
Does it work in Google Sheets?
Yes. Excel files open in Microsoft Excel, Google Sheets and LibreOffice. Word files open in Word and Google Docs.
How do I get the files?
The download link appears right after payment and is emailed to you. You can download again from My Account for 365 days.
Can my team use it?
Yes, anyone in your own organisation may use it. Please do not resell or publish the files.
Need a panel? Wavetech Electricals Pvt. Ltd. designs and builds HVAC starter and MCC panels in Mumbai for customers in India and abroad. Get a panel quote.
